รายละเอียดสินค้า |
OutputOutput power capacity
540Watts / 900VA
Max Configurable Power (Watts)
540Watts / 900VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Output Frequency (not synced)
50/60 Hz +/-1 Hz
Load Crest Factor
3 : 1
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(4) IEC 320 C13 (selector_surgetitle)
(2) IEC Jumpers (Battery Backup)
(4) IEC 320 C13 (Battery Backup)
Transfer Time
8ms typical : 10 ms maximum
Bypass
Built-in Bypass
InputNominal Input Voltage
230V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
176 - 294V
Input voltage adjustable range for mains operation
156 - 300V
Number of Power Cords
1
Maximum Input Current
8.0A
Batteries & RuntimeBattery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
8hour(s)
Replacement Battery
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Battery Volt-Amp-Hour Capacity
157
Runtime
Efficiency
Communications & ManagementInterface Port(s)
Optional Simple Signalling RS232 cable, USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and FilteringSurge energy rating
613Joules
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous
PhysicalMaximum Height
250MM, 25.0CM
Maximum Width
100MM, 10.0CM
Maximum Depth
382MM, 38.2CM
Net Weight
10.72KG
Shipping weight
11.7KG
Shipping Height
337MM, 33.7CM
Shipping Width
225MM, 22.5CM
Shipping Depth
487MM, 48.7CM
Color
Black
Master Carton Units
1.0
Pallet Dimensions
46inches
Pallet Weight
865.22lbs.
Units per Pallet
30.0
SCC Codes
1073130427959 1
EnvironmentalOperating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-2952.6meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-14763.6meters
Audible noise at 1 meter from surface of unit
45.0dBA
ConformanceApprovals
A-tick, C-tick, CE, GS Mark
Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP
Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries
Sustainable Offer StatusRoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
![]() ![]() |
